Swagelok battery test cell

Three-electrode battery test cell

Model: B001-1

●Pool body material PEEK

●Three-electrode system

●Reference electrode silver silver chloride

●The conductive medium that connects the positive and negative electrodes is glass carbon electrode (GC-Medium 3)

●The positive and negative electrodes are the tested samples, and the film is sandwiched between the two tested samples

●Used to simulate button battery test

●By tightening the glassy carbon electrodes on the left and right sides, the positive and negative electrodes are compressed to conduct electricity to achieve the battery test effect

●Unscrew the reference electrode and add liquid

●The size of the electrolytic cell sample is 10/12/16mm

Two-electrode battery test cell

Model: B001-2

●Pool body material PEEK

●Two electrode system

●The conductive medium that connects the positive and negative electrodes is glass carbon electrode (GC-Medium 3)

●The positive and negative electrodes are the tested samples, and the film is sandwiched between the two tested samples

●Used to simulate button battery test

●By tightening the glassy carbon electrodes on the left and right sides, the positive and negative electrodes are compressed to conduct electricity to achieve the battery test effect

●Unscrew the upper end of the liquid inlet and outlet screws, which contain gas phase pads

●The size of the electrolytic cell sample is 10/12/16mm
